      SLANT TURN NEXUS 500




      MACHINE DESCRIPTION:

      The SLANT TURN NEXUS 500 CNC Turning Center is a powerful, high torque, heavy-duty, big bore Turning Center for large part turning applications such as oil field pipe /casings, pipeline control valves, turbine wheels, components, and aircraft engine parts. The machine offers maximum machining lengths up to 160", and depending on chuck size, maximum machining diameters to 36", for long, large-diameter parts.

      MACHINE CHARACTERISTICS:

      • High torque, high horsepower geared headstocks for heavy-duty cutting
      • 12-position Non lift drum turrets for rapid tool indexing
      • NC servo-driven tailstocks
      • Mazak MX Hybrid Roller Guide System
      • MATRIX NEXUS 2 CNC control

      机床参数

      zoom
      Specification 中心距 - 1000U in 中心距 - 2000U in 中心距 - 3000U in 中心距 - 4000U in
      加工能力 最大回转直径 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in
      最大加工直径 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in
      最大加工长度 1047 mm / 41.300 in 2040 mm / 80.310 in 3175 mm / 125.000 in 4064 mm / 160.000 in
      主轴 卡盘尺寸 18 in 18 in 18 in 18 in
      最大转速 1600rpm 1600rpm 1600 rpm 1600 rpm
      电机功率 (30 分钟额定) 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp
      上刀塔 刀具数量 12 12 12 12
      进给轴 行程(X轴) 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in
      行程(Z轴) 1175 mm / 46.26 in 2165 mm / 85.24 in 3300 mm / 129.92 in 4190 mm / 164.96 in
      行程(W轴) 870 mm / 34.25 in 2083 mm / 82.01 in 3218 mm / 126.69 in 3890 mm / 153.15 in

      SLANT TURN NEXUS 500M



      MACHINE DESCRIPTION:

      The SLANT TURN NEXUS 500M CNC Turning Center is a powerful, high torque, heavy-duty, big bore Turning Center for large part turning applications such as oil field pipe /casings, pipeline control valves, turbine, components, and aircraft engine parts. The machine offers maximum machining lengths up to 160", and depending on chuck size, maximum machining diameters to 36", for long, large-diameter parts. STN500M machines also offer rotary tool capability for secondary drilling and milling operations on centerline.

      MACHINE CHARACTERISTICS:

      • High torque, High Horsepower geared headstocks for heavy-duty cutting
      • 12-position Non lift turrets for rapid tool indexing
      • Spindle C-axis positioning for slotting cuts and precision drilled holes
      • Powerful Rotary Tool turret for secondary mill/drill operations
      • NC servo-driven tailstocks
      • Mazak MX Hybrid Roller Guide System
      • MATRIX NEXUS 2 CNC control

      机床参数

      zoom
      Specification 中心距 - 1000U in 中心距 - 2000U in 中心距 - 3000U in 中心距 - 4000U in
      加工能力 最大回转直径 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in
      最大加工直径 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in
      最大加工长度 1082 mm / 42.570 in 2075 mm / 81.690 in 3210 mm / 126.380 in 4099 mm / 161.320 in
      主轴 卡盘尺寸 18 in 18 in 18 in 18 in
      最大转速 1600rpm 1600rpm 1600 rpm 1600 rpm
      电机功率 (30 分钟额定) 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp
      上刀塔 刀具数量 12 12 12 12
      最大转速 4000rpm 4000rpm 4000 rpm 4000 rpm
      电机功率 (4 分钟额定) 8 kw / 10.0 hp 8 kw / 10.0 hp 8 kw / 10.0 hp 8 kw / 10.0 hp
      进给轴 行程(X轴) 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in
      行程(Z轴) 1175 mm / 46.26 in 2165 mm / 85.24 in 3300 mm / 129.92 in 4190 mm / 164.96 in
      行程(W轴) 870 mm / 34.25 in 2083 mm / 82.01 in 3218 mm / 126.69 in 3890 mm / 153.15 in

      SLANT TURN NEXUS 550




      MACHINE DESCRIPTION:

      The SLANT TURN NEXUS 550 CNC Turning Center is a powerful, high torque, heavy-duty, big bore Turning Center for large part turning applications such as oil field pipe /casings, pipeline control valves, turbine, components, and aircraft engine parts.

      The machine offers maximum machining lengths up to 160", and depending on chuck size, maximum machining diameters to 36", for long, large-diameter parts.

      MACHINE CHARACTERISTICS:

      • High torque, High horsepower geared headstocks for heavy-duty cutting
      • Various big bore spindles available, with front and rear chuck options
      • 12-position Non lift drum turrets for rapid tool indexing
      • NC servo-driven tailstocks
      • Mazak MX Hybrid Roller Guide System
      • MATRIX NEXUS 2 CNC control

      机床参数

      zoom
      Specification 中心距 - 1000U in 中心距 - 2000U in 中心距 - 3000U in 中心距 - 4000U in
      加工能力 最大回转直径 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in
      最大加工直径 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in
      最大加工长度 1016 mm / 40.090 in 2009 mm / 79.090 in 3144 mm / 123.780 in 4033 mm / 158.800 in
      主轴 卡盘尺寸 21 in 21 in 21 in 21 in
      最大转速 1000rpm 1000rpm 1000 rpm 1000 rpm
      电机功率 (30 分钟额定) 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp
      上刀塔 刀具数量 12 12 12 12
      进给轴 行程(X轴) 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in
      行程(Z轴) 1175 mm / 46.13 in 2165 mm / 85.24 in 3300 mm / 129.88 in 4190 mm / 164.88 in
      行程(W轴) 870 mm / 34.25 in 2083 mm / 82.01 in 3218 mm / 126.69 in 3890 mm / 153.13 in

      SLANT TURN NEXUS 600


      MACHINE DESCRIPTION:

      The SLANT TURN NEXUS 600 CNC is a powerful, heavy-duty,high torque, big bore Turning Center for large part turning applications such as oil field pipe /casings, pipeline control valves, turbine components, and aircraft engine parts.

      The STN600 offers maximum machining lengths up to 160", and depending on chuck size, maximum machining diameters to 36", for long, large-diameter parts. The standard spindle bore is 14.7" diameter and can handle large diameter pipe and other components that required front and rear chucking.

      MACHINE CHARACTERISTICS:

      • High torque, High Horsepower geared headstocks for heavy-duty cutting
      • Various front and rear chuck options available
      • 14.7" diameter Spindle Bore
      • 12-position Non lift drum turrets for rapid tool indexing
      • NC servo-driven tailstocks
      • Mazak MX Hybrid Roller Guide System
      • MATRIX NEXUS 2 CNC control

      机床参数

      zoom
      Specification 中心距 - 2000U in 中心距 - 3000U in 中心距 - 4000U in
      加工能力 最大回转直径 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in
      最大加工直径 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in
      最大加工长度 2009 mm / 79.090 in 3144 mm / 123.780 in 4033 mm / 158.780 in
      主轴 卡盘尺寸 21 in 21 in 21 in
      最大转速 500 rpm 500 rpm 500 rpm
      电机功率 (30 分钟额定) 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp
      上刀塔 刀具数量 12 12 12
      进给轴 行程(X轴) 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in
      行程(Z轴) 2165 mm / 85.24 in 3300 mm / 129.92 in 4190 mm / 164.96 in
      行程(W轴) 2083 mm / 82.01 in 3218 mm / 126.69 in 3890 mm / 153.15 in

      SLANT TURN NEXUS 600M




      MACHINE DESCRIPTION:

      The SLANT TURN NEXUS 600M CNC is a powerful, high torque, heavy-duty, big bore Turning Center for large part turning applications such as oil field pipe /casings, pipeline control valves, turbine, components, and aircraft engine parts.

      The STN600M offers maximum machining lengths up to 160", and depending on chuck size, maximum machining diameters to 36", for long, large-diameter parts. The spindle bore is 14.7" diameter and can handle large diameter pipe and other components that required front and rear chucking. STN600M machines also offer powerful rotary tool capability for secondary drilling and milling operations on centerline.

      MACHINE CHARACTERISTICS:

      • High torque, High Horsepower geared headstocks for heavy-duty cutting
      • Spindle C-axis positioning for slotting cuts and precision drilled holes
      • Various front and rear chuck options available
      • 14.7" diameter Spindle Bore
      • 12-position Non lift turrets for rapid tool indexing
      • Powerful Rotary Tool turret for secondary mill/drill operations
      • NC servo-driven tailstocks
      • Mazak MX Hybrid Roller Guide System
      • MATRIX NEXUS 2 CNC control

      机床参数

      zoom
      Specification 中心距 - 2000U in 中心距 - 3000U in 中心距 - 4000U in
      加工能力 最大回转直径 1040 mm / 40.94 in 1040 mm / 40.94 in 1040 mm / 40.94 in
      最大加工直径 910 mm / 35.830 in 910 mm / 35.830 in 910 mm / 35.830 in
      最大加工长度 2044 mm / 80.470 in 3179 mm / 125.160 in 4068 mm / 160.160 in
      主轴 卡盘尺寸 21 in 21 in 21 in
      最大转速 500 rpm 500 rpm 500 rpm
      电机功率 (30 分钟额定) 45 kw / 60.0 hp 45 kw / 60.0 hp 45 kw / 60.0 hp
      上刀塔 刀具数量 12 12 12
      最大转速 4000 rpm 4000 rpm 4000 rpm
      电机功率 (4 分钟额定) 8 kw / 10.0 hp 8 kw / 10.0 hp 8 kw / 10.0 hp
      进给轴 行程(X轴) 465 mm / 18.31 in 465 mm / 18.31 in 465 mm / 18.31 in
      行程(Z轴) 2165 mm / 85.24 in 3300 mm / 129.92 in 4190 mm / 164.96 in
      行程(W轴) 2083 mm / 82.01 in 3218 mm / 126.69 in 3890 mm / 153.13 in
