VTC-160AN

机床参数

VTC-160AN-2PC

机床参数

VTC-250D/50

MACHINE DESCRIPTION:

The VERTICAL TRAVELING COLUMN (VTC) 250D Vertical Machining Center features a powerful 50 Taper High Torque spindle, full traveling column design and fixed table for machining of extremely long and heavy workpieces. Or with a table center partition the machine work envelop can be transformed into two separate work areas that allow the machine to be in cycle in one work area, while a part is being set up in the other work area. The machine also delivers fast rapid traverse rates to reduce non-cut times.

MACHINE CHARACTERISTICS:

• Long fixed table design with split table capability
• 6,000 RPM, 50-taper High Torque spindle
• 1,181 ipm rapid traverse rate
• 24-tool storage capacity
• Maximum table load of 3,000 lbs.

机床参数

VTC-530/20

机床参数

VTC-800/30SR

MACHINE DESCRIPTION:

The VERTICAL TRAVELING COLUMN (VTC) 800/30 SR Vertical Machining Center features a high speed 40 Taper spindle, swivel spindle head (B Axis), full traveling column design and fixed table for machining of extremely long and heavy workpieces. Or with an optional table partition, the long machine table can be transformed into two separate work areas. The Roller Gear Cam design swivel head delivers improved accuracy and repeatability due to the backlash free design, which allows the machining of complex features and contours. These features offer excellent machining capacity for a large variety of work pieces.

A significant reduction of machining processes and increased productivity can be realized thanks to the additional axis, and when combined with a rotary table, full 5-axis simultaneous machining is possible. The machine also delivers fast rapid traverse rates to reduce non-cut times.

MACHINE CHARACTERISTICS:

• 18,000 RPM 40 Taper Spindle
• Swivel Spindle Head (B Axis +/- 110 degrees)
• 30 Tool Std, Optional 48 Tool Magazine
• Full 5 axis contouring with optional rotary table
• Table Center Partition-OPT
• Max Table Load 5,500 lbs

机床参数
